Code: P0545 - The exhaust gas temperature sensor (EGT sensor) before the catalytic converter on bank 1 is reporting a low signal, possibly due to a sensor or wiring issue.

When you see a P0545 code, you’re dealing with an issue tied to the Exhaust Gas Temperature (EGT) sensor on bank 1-that’s the side with cylinder number one. Over the years, I’ve found this little sensor is usually tucked into the exhaust right before the catalytic converter, or in diesels, ahead of the DPF. Its job? Keeping tabs on exhaust temps to prevent the cat from getting fried. The sensor works by changing its resistance as it heats up, and that’s the signal your engine’s computer relies on. If the reading drops too low, meaning the computer thinks the exhaust is a lot cooler than it really is, up pops the P0545 code. In a nutshell, your car’s brain is getting bad info about exhaust temps, which can throw off emissions controls and, in diesels, mess with those all-important regen cycles.

Causes of dtc P0545

From experience, the most common reasons for a P0545 code are pretty straightforward. Here’s what I usually find:

Loose, corroded, or damaged connectors at the EGT sensor-this is a big one, especially on older vehicles or those exposed to harsh weather.
Broken or shorted wiring going to the sensor, sometimes from heat damage or rubbing against something sharp.
A failed EGT sensor itself-these do wear out over time, especially if the engine runs hot or the vehicle is used for towing.
Aftermarket exhaust modifications, like removing the catalytic converter or installing a straight pipe, can also trigger this code because the sensor can’t work properly without the right backpressure.
Very rarely, a problem with the engine computer, but honestly, that’s the last thing I’d suspect.

Symptoms of P0545 code

When this code pops up, the main thing you’ll notice is the check engine light coming on. Most folks don’t feel any difference in how the car drives-no rough running, no loss of power, nothing obvious. But don’t let that fool you. The car’s computer is still reacting behind the scenes, and if you drive a diesel, it might mess with the regeneration cycle for the particulate filter. So, even if the car feels fine, there’s still a problem that needs attention.

Diagnosis steps for obd code P0545

Here’s how I tackle a P0545 code, step by step. I always start with the basics before diving into anything complicated:

First, I locate the EGT sensor on bank 1. It’s usually between the exhaust manifold and the catalytic converter, or before the DPF on diesels. If you’re not sure, check your service manual or ask for help-these can be tucked away in tight spots.
Next, I inspect the sensor’s connector. I look for corrosion, loose pins, or any signs of water or dirt getting in. If it’s dirty or corroded, clean it up and make sure it clicks back together firmly.
Then, I follow the wiring from the sensor back to its harness. I’m looking for any spots where the insulation is missing, wires are pinched, or anything looks burnt. Any damage here can cause the code.
If the wiring and connectors look good, I unplug the sensor and check its resistance with a multimeter. A healthy EGT sensor should read about 150 ohms. If it’s much lower-say, under 50 ohms-it’s time to replace the sensor.
For a more thorough check, I heat the sensor gently with a heat gun while watching the resistance. The reading should drop as the sensor gets hotter. If it doesn’t change, the sensor’s no good.
Finally, I check the voltage at the harness side with the key on. You should see 5 volts from the computer. If you don’t, there could be a deeper electrical issue, possibly with the computer itself, but that’s rare.

It’s best to have someone assist you during these checks, especially when working under the car or dealing with hot components. Don’t forget to let things cool down before touching the exhaust!

Common mistakes when fixing P0545 engine code

I’ve seen folks jump straight to replacing the EGT sensor without checking the wiring or connectors first. That’s a surefire way to waste money. Another common mistake is confusing the EGT sensor with the oxygen sensor-they look different, and the EGT usually has just two wires. Skipping the resistance test or not checking for corrosion at the connector can also lead to misdiagnosis. Always start with the simple stuff before swapping out parts.

How serious is the P0545 trouble code

This isn’t something to ignore. While you might not notice any drivability issues right away, letting this go can lead to bigger problems. If the sensor isn’t working, the catalytic converter or DPF can overheat and get damaged-those are expensive parts to replace. On diesels, improper regeneration can clog the filter, causing power loss or even engine damage. Honestly, things can go south quickly if you put this off, so it’s best to get it sorted out as soon as possible.

Repair solutions for P0545

The most reliable fixes I’ve seen for P0545 are:

Cleaning or repairing any corroded or loose connectors at the EGT sensor.
Repairing or replacing damaged wiring between the sensor and the computer.
Replacing the EGT sensor itself if it fails the resistance or heat test.
If the exhaust has been modified, restoring the original system is the only way to get things working right again.
In extremely rare cases, replacing the engine computer, but I’d only go there after ruling out everything else.

Conclusion

To sum it up, P0545 means your exhaust gas temperature sensor on bank 1 isn’t sending the right signal, usually because of a bad sensor, wiring issue, or connector problem. Even if your car feels fine, this code can lead to serious and expensive damage if ignored. I always recommend starting with a careful inspection of the wiring and connectors, then testing the sensor itself. Most of the time, fixing the wiring or swapping out the sensor gets you back on the road safely. Don’t put this off-taking care of it now will save you a lot of trouble down the line.
